Product Analysis
Environmental Requirements
| Environmental temperature: 10 ℃~35 ℃ | Relative humidity: ≤ 40% -60% | Weight: 28kg |
| FP qualitative and quantitative analysis software | External dimensions: 340 * 340 * 420 | Power requirement: 220V |
Technical Specifications
| High voltage power supply: 0-50KV | Detector: Si pin |
| Light tube voltage: 5-50KV | Multi channel analyzer: 4096 channel address multi channel analyzer JPSpec DPP |
| Light tube flow: 0-1000 μ A | Sample cavity size: 280 * 280 * 70mm |
| Filter: Multiple customization options available for switching | Test time: 30-100s |
Advantages and Characteristics
| Easy to use: One click operation can obtain analysis results of carat grade and composition | Innovative Function: Helps identify innovative features of gold-plated samples |
| Product design: The body structure is compact and sturdy, with a beautiful appearance, suitable for placement in display rooms | Fast detection: Accurate results on the chemical composition and carat grade of the sample can be detected within seconds |
| Software function: Use PC and software to facilitate the production of test result certificates for samples | Lighting system: Users can see the detection position of the sample through the camera and cabin lighting system, which enhances testing confidence |
| Data download: Test data can be uploaded and downloaded online, and the test results are easy to view and share | Security protection: With an X-ray protection lock, X-rays are only emitted in a closed state, ensuring safe and reliable use by customers |
Application Examples
Accurate analysis of testing precious metals Au/Pt/Ag/Pd
On site carat level appraisal of gold: 0-24kt
Verify the gold content in scrap metals
Identify impurity materials
Identify unknown metals
Application fields of BXR-686 precious metal analyzer
| Jewelry manufacturing | Quality and Technical Supervision Bureau | Cash gold exchange |
| Recycling industry | Retail industry | Pawnshops/Refining Industry |
