Simplified configuration
|
The gas chromatograph adopts the advanced 10/100M adaptive Ethernet communication interface and built-in IP protocol stack, so that the instrument can easily realize long-distance data transmission through the enterprise internal LAN and Internet; Facilitating the setup of the laboratory, simplifying the configuration of the laboratory, and facilitating the management of analytical data;
|
|
Three independent connection processes are designed inside the instrument, which can be connected to local processing (laboratory site), making it convenient for unit supervisors and superiors to monitor the operation of the instrument in real time and analyze data results;
|
|
Cost reduction
|
The NetChromTM workstation equipped with the instrument can support the operation of multiple chromatographs simultaneously, enabling data processing and control, simplifying document management, and greatly reducing users' laboratory investment and operating costs;
|
|
Comprehensive system
|
The instrument can be connected to the manufacturer through the Internet to realize remote diagnosis, remote program update, etc. (with the user's permission);
|
|
The instrument is equipped with a 5.7-inch true color display screen, which displays clear, elegant color tones, and high-end atmosphere;
|
|
The system has two operating systems in Chinese and English, which can be freely switched. The randomly equipped workstation is suitable for Chinese and English operating systems such as WinXP, Win2000, Win7, Win10, etc;
|
|
The temperature control area can be freely named by users for convenient use;
|
|
The instrument adopts a modular structural design, which is clear in design, easy to replace and upgrade, and protects the effectiveness of investment;
|
|
A brand new microcomputer temperature control system with high temperature control accuracy, superior reliability and anti-interference performance; Equipped with a six channel fully independent temperature control system, it can achieve sixteen step programmed temperature rise, enabling the device to handle a wider range of sample analysis; Equipped with a column box automatic rear door opening system, the precision of low-temperature control is improved, and the speed of temperature rise/fall is faster;
|
|
The instrument can be equipped with advanced electronic flow controllers (EFC) and electronic pressure controllers (EPC) to achieve digital control of the gas path, which can greatly improve the stability and reproducibility of quantitative results;
|
|
The chromatography machine is equipped with a low-noise, high-resolution 24 bit AD circuit and has the functions of baseline storage and baseline subtraction;
|
|
The chromatographic system has a standard interface of MODBUS/TCP, which can be easily integrated with DCS;
|
