BXR-686Precious metal analyzer

Product introduction：
Application areas: Jewelry manufacturing, recycling industry, Quality and Technical Supervision Bureau, retail industry, cash and gold exchange, pawn shops/refining industry

Online consultation Back to list

Product Analysis

Environmental Requirements

Environmental temperature: 10 ℃~35 ℃	Relative humidity: ≤ 40% -60%	Weight: 28kg
FP qualitative and quantitative analysis software	External dimensions: 340 * 340 * 420	Power requirement: 220V

Technical Specifications

High voltage power supply: 0-50KV	Detector: Si pin
Light tube voltage: 5-50KV	Multi channel analyzer: 4096 channel address multi channel analyzer JPSpec DPP
Light tube flow: 0-1000 μ A	Sample cavity size: 280 * 280 * 70mm
Filter: Multiple customization options available for switching	Test time: 30-100s

Advantages and Characteristics

Easy to use: One click operation can obtain analysis results of carat grade and composition	Innovative Function: Helps identify innovative features of gold-plated samples
Product design: The body structure is compact and sturdy, with a beautiful appearance, suitable for placement in display rooms	Fast detection: Accurate results on the chemical composition and carat grade of the sample can be detected within seconds
Software function: Use PC and software to facilitate the production of test result certificates for samples	Lighting system: Users can see the detection position of the sample through the camera and cabin lighting system, which enhances testing confidence
Data download: Test data can be uploaded and downloaded online, and the test results are easy to view and share	Security protection: With an X-ray protection lock, X-rays are only emitted in a closed state, ensuring safe and reliable use by customers

Application Examples

Accurate analysis of testing precious metals Au/Pt/Ag/Pd
On site carat level appraisal of gold: 0-24kt
Verify the gold content in scrap metals
Identify impurity materials
Identify unknown metals
